Drinking Water blow molding machines series is a stable two-step blow-down stretch automatic blowing machine.It can be used from 4 cavity to 8 cavity with a speed of 1500 bottles per cavity In one hour(750 ml plastic bottles),max volume 2L plastic bottle,suitable for blowing any kind of carbonated beverage bottle,sparkling beverage bottle,pure water bottle, mineral water bottle,fruit juice beverage bottle,cosmetic bottles,large diameter bottles, high temperature resistance bottles and other packaging bottles.

	Item	Shuanghao-4	Meto-6	Meto-8
Bottle type specification	Cavity	4	6	8
	Theory output	8000-1000BPH	12000-15000BPH	16000-20000BPH
	Max.volume	2L	2L	2L
	Bottle mouth maximum overall diameter	28-38mm	28-38mm	28-38mm
	Bottle biggest diameter	100mm	100mm	100mm
	Bottle maximun height	330mm	330mm	330mm
Power specification	Light tube quantity	16pcs	32pcs	32pcs
	Light tube power	1.25KW	1.25KW	1.5KW
	Maximum heating pwoer	20KW	40KW	48KW
	All electric machine installtion	29KW	49KW	65KW
	Actual consumption	30%-60%	30%-60%	30%-60%
Air pressure specification	Work pressure	5-6kg/cm²	5-6kg/cm²	5-6kg/cm²
	Blow bottle pressure	25-45kg/cm²	25-45kg/cm²	25-45kg/cm²
	Higher-pressure ges consumption	6000Ltr/min	8000Ltr/min	12000Ltr/min
Forzen water specification	Work pressure	5-6 kg/cm²	5-6 kg/cm²	5-6 kg/cm²
	Temperature range	10℃	10℃	10℃
	Consumption	8000kcal/hr	8000kcal/hr	12000kcal/hr
	Forzen water flow	88L/min	120L/min	150L/min
Machine specification	Size of the machine	3.6×1.6×1.9	4.8×1.8×1.9	5.78×1.6×1.9
	Weight of the machine	4.3ton	6.1ton	7.45ton

Meto is a linear bottle blowing machine which is developed and researched by the most advanced bottom making technology in the current world and molded through blowing PET(Polyethylene Terepthalate)by high pressure compressed gas.The machine needs a bottle blank appropriate to bottle type.this linear bottle blowing machine can be used independently for blowing bottles or completion of bottle blowing before filling lines.

The machine shows characteristics such as high intelligence,stable and reliable mechanical performance, high production efficiency,low cost and pollution free from intermediate process,it is widely used for production of food,drink,cosmetic and medical vessel.

1.DETAILED IMAGES

Shuanghao machine seiko to create quality details

2.Cooperated Brand

The main parts of The machines are from Germany, Japan, Switzerland, Korea, Taiwan and so on, They can make 10ml-25L bottles and barrels and jars with different designs and shapes with PET, PP, PE and other material. Our machines are sold to Malaysia, lndonesia, Thailand, Nigeria, Ecuador, Colombia, Paraguay, and many other countries and regions.To produce machines with the best quality and simple operation and with the best price is the aim for Meto Machinery to strive for.

3.Product Features

• Stable and accurate running at high speed,adopt more stable and advanced microcomputer PLC control system.
• Production process is fully automated, with the advantages of low investment, high efficiency, easy operation, simple maintenance and safety.
• Suitable for flexible production of quantity and various bottle shape,wide range of applications,meet customer needs.
• Manual and automatic methods of operation, human-machine interface control, simple operation.
• Servo transmission system, high positioning accuracy, fast speed stability and good reliability.

4.Working Process
